Aperçu /Produits/Inverseur basse fréquence/Invertor dc 12v to ac 220v car inverter 500w car power inverter charger for phones and laptops 345*170*290~490*260*500

Invertor dc 12v to ac 220v car inverter 500w car power inverter charger for phones and laptops 345*170*290~490*260*500

10 sets
MOQ
Invertor dc 12v to ac 220v car inverter 500w car power inverter charger for phones and laptops 345*170*290~490*260*500
traits Galerie Description de produit Demandez une citation
traits
Caractéristiques
Model Number: SSI001
Input Voltage: 48/96V
Output Voltage: 220
Output Current: 0~20A
Output Frequency: 45Hz~55Hz(50Hz) / 55Hz~65Hz(60Hz)
Output Type: Single
Size: 345*170*290~490*260*500
Type: DC/AC Inverters
Inverter Efficiency: >99%
Certificate: CE,RoHS,IS9001
Warranty: 3 Years
Weight: 65~ 189
Charging Mode: PWM or MPPT
Output Voltage:: 110VCA/120VCA/220VCA/ 230VCA/240VCA
Output Efficiency(Battery Mode): ≥85%
Wandlungszeit: ≤4ms
Communication(Optional): RS232/RS485/APP/SNMP/GSM optional
Temperature: 0°C~40°C
Humidity: 10%~90%(no condensate)
Rauschen: ≤55dB
Color: black
Display:: LCD
Informations de base
Certification: CE,RoHS,IS9001
Model Number: SSI001
Conditions de paiement et expédition
Packaging Details: package
Supply Ability: 2000 Set/Sets per Month
Description de produit
Detailed Images
1,LCD Display Visually display the voltage, frequency and working mode, load power, etc.

2,Function 1 Mute button
ON/OFF button

3,Customer trademarks can be printed

4,Natural heat dissipation holes
5,Intelligent cooling fanAutomatically modulating the fan's rotationalspeed according to internal temperature

6,AC Input Interface
Can be connected to grid power or generatorsto provide voltage stabilized power for AC loadand charge batteries at the same time

7,AC output universal socket
Compatible with any plug on the market

8,Battery positive andnegative terminal

Feature :

• Pure sine wave output;
• Wide AC voltage input range, AVR output;
• Adopt traditional El transformer, stable performance;
• LCD real-time display, concise and straightforward;
• Working modes: AC first or battery first optional, intelligent charging;
• Built-in MPPT or PWM charge controller optional;
• RS232 communication port optional.
Model Number
SSI001
Rated Power
500W
1000W
3000W
5000W
8KW
10KW
20KW
30KW
40KW
Peak Power
1500VA
3000VA
9000VA
15000VA
24KVA
30KVA
60KVA
90KVA
120KVA
Start Motor
0.5HP
1HP
3HP
4HP
6HP
7HP
10HP
15HP
20HP
Size(W×D×H)mm
335*210*122
410*143*210
420*208*348
460*245*445
485*300*646
600*300*800
720*435*1120
Net weight(kg)
8
13
29
52
64
66
113
135
160
General parameters











    Input
DC Input Voltage Range
10.5-15VDC(Single battery voltage)
AC Input Voltage Range
73VAC· 138VAC(110VAC)/ 83VAC~ 148VAC(120VAC) / 145VAC-275VAC(220VAC) /155VAC~285VAC(230VAC) /165VAC~ ·295VAC( 240VAC)(700W~7000W)
92VAC~128VAC(110VAC)/ 102VAC~138VAC(120VAC)/ 185VAC~255VAC(220VAC)/195VAC~ -265VAC(230VAC)/ 205VAC~275VAC( 240VAC) (8KW~40KW)
AC Input Frequency Range
45Hz· 55Hz(50Hz) 155Hz~65HZ(60Hz)
Max AC charging current
6A~15A(Depending on the model)
AC charging voltage
LEAD battery:Charge Voltage :14.2V; Float Voltage:13.8V(Single battery voltage)
AC charging method
Three-stage (constant current, constant voltage, floating charge)





















 Output
Efficiency(Battery Mode)
≤85%
Output Voltage(Battery Mode)
110VACt2% 1 120VACt2% 1 220VACt2% 1 230VACt2% 1 240VACt2%
Output Frequency(Battery Mode)
50Hz+0.5 or 60Hzt0.5
Output Wave(Battery Mode)
Pure Sine Wave
Eficiency(AC Mode)
>99%

Output Voltage(AC Mode)
Follow input
Output Frequency(AC Mode)
Tracking Automatically
Output waveform distortion(Battery Mode)
≤3%(Linear load)
No load loss(Battery Mode)
≤2.5% rated power(Models below 7KW);<1% rated power(models above 7KW)
No load loss(AC Mode)
≤2% rated power( charger does not work in AC mode)
No load loss(Energy saving Mode)
<10W



Battery Type
VRL A Battery
Charge Voltage :14.2V; Float Voltage:13.8V(Single battery voltage)
Customize battery
Charge and discharge parameters of different types of batteries (such as lithium batteries,etc.) can be customized according to user requirements












Protection
Battery undervoltage alarm
Factory default: 11V(Single battery voltage)
Battery undervoltage protection
Factory default: 10.5V(Single battery voltage)
Battery overvoltage alarm
Factory default: 15V(Single battery voltage)
Battery overvoltage protection
Factory default: :17V(Single battery voltage)
Battery overvoltage recovery voltage
Factory default: 14.5V(Single battery voltage)
Overload power protection
Automatic protection (battery mode), circuit breaker or insurance (AC mode)
Inverter output short circuit protection
Automatic protection (battery mode), circuit breaker or insurance (AC mode)
Temperature protection
> 90'C(Shut down output)



      Alarm
A
Normal working condition, buzzer has no alarm sound
B
 Buzzer sounds 4 times per second when battery failure, voltage abnormality, overload protection
C
When the machine is turned on for the first time, the buzzer will prompt 5 when the machine is normal

















Inside Solarcontroller(Optional)
Charging Mode
PWM
Charging current
12V/24V/48V System: 10A/20A/30A/40A/50A/60A; 96V/192V/240V/384 System:

50A/100A/1 50A/200A
PV Input Voltage Range
15V-44V(12V System); 30V- -44V(24V System); 60V-88V(48V System); 120V-176V(96VSystem); 240V-352V(192V System); 300V-440V(240V System); 480V-704V(384V System)
Max PV Input Voltage(Voc)(At the lowest temperature)
50V(12V/24V System); 100V(48V System); 200V(96V System); 400V(192V System);500V(240V System); 750V(384V System)
PV Array Maximum Power
12V System: 140W(10A)/280W(20A)/420W(30A)/560W(40A)/700W(50A)/840W(60A); 24VSystem: 280W(10A)/560W(20A)/840W(30A)/1120W(40A)/1400W(50A)/1680W(60A);48V System:
560W(10A)/1120W(20A)/1680W(30A)/2240W(40A)/2800W(50A)/3360W(60A);96V System: 5.6KW(50A)/11.2KW(100A) ; 192V System: 11 .2KW(50A)/22.4KW(100A);220V System: 12.8KW(50A)/25.6KW(100A); 240V System:14KW(50A)/28KW(100A)/21KW*2(1 50A)/28KW*2(200A); 384V System:22. 4KW(50A)/44.8KW(100A)/33.6KW*2(150A)/44.8KW*2(200A)

Standby loss
≤3W
Maximum conversion efficiency
>95%
Working Mode
Battery First/AC First/Saving Energy Mode
Transfer Time
≤4ms
Display
LCD
Thermal method
Cooling fan in intelligent control
Communication
RS232(Optional)






Environment
Operating temperature
-10"C ~40'C
Storage temperature
-15"C~60"C
Noise
≤55dB
Elevation
2000m(More than derating)
Humidity
0%~95% ,No condensation

Exclusive Feature

1,Sola POW three phase solar pv system is the most complete configuration on the market, which includes all necessary components: solar panel, solar bracket, PV combiner box, solar battery, three phase solar inverter, solar charge controller, pv cables,battery cables and other terminals. After the simple installation is complete, it can be directly used for residential appliances.
2,Each set three phase solar pv system has power on&off test 100 times per hour. Each step of production is under strict quality control. Perfect protection: short circuit, over-voltage, low-voltage, overload, insulation resistance, high temperature
protection.
3,Sola POW solar pv system range is from 300W to 100KW. We provide customers with free solar solution design and can accept customization.
Product Paramenters

1. Adopt low frequency transformer, pure sine wave AC output, strong capacity of different load 2. Auto voltage
regulation(AVR),wide input voltage 145V~275V, accurate output, adapt all kinds of bad electric environments 3. Intelligent battery
charging, the charging current can be adjusted according to the equipped battery, it is fast and reliable and can increase the
service life of the battery 4. Intelligent LCD display of output voltage,frequency,battery capacity,fault,over load,load 5. User
can use the program of RS232 or USB communication software to monitor the inverter and set time auto shut down 6. Satisfy the
power supply for different back up time 7. It can be automatically started up with mains supply, and has a wider range of
applications 8. Advanced automatic constant charging circuit, prolongs battery life 9. It has perfect protection against
under-voltage, overload, over-discharge, short-circuit etc.
